鑲熱管 鑲銅管散熱器

當空間受限或者通風不暢時，鑲熱管或鑲銅管散熱就成為一個很好選擇。

熱管能水平放置來解決空間高度受限而達到散熱需要。通常由于有障礙物阻擋空氣不能自由流動來冷卻設備，我們用熱管將蒸發器與遠端的被阻塞通風的冷凝器連接起來以達到冷卻效果。

銅有更好的熱導性，但當鋁質底座不能承受其重量時，用較輕的熱管來代替銅板也可以起到所需要的散熱效果。熱管也可以鑲嵌在銅質底座里以減小質量來達到散熱效果。

使用熱管后，不需使用電扇來散熱并能以低轉速來運轉系統，這樣帶來的直接好處是能提供系統工作的穩定性和降低維護費用。相對傳統的散熱解決方案，在低速空氣流動情況下用熱管也能提高散熱效果。

Transport designs can be useful where space is constrained or airflow is not available directly over the device requiring cooling. Examples of application characteristics where transport heat pipes solutions may solve design issues include:

Limited height or space—Heat pipes can spread the cooling solution volume horizontally rather than vertically to achieve the desired thermal performance.

Obstructed airflow—Obstructions in the chassis may leave insufficient airflow over the device to be cooled. Connecting an evaporator to a remote condenser using a heat pipe allows the condenser to be placed in an area of unobstructed airflow to provide the necessary cooling.

Heat pipes can be added to an aluminum base when the use of higher thermally conductive metal like copper cannot be tolerated due to weight. Heat pipes can also be embedded in copper bases to increase spreading without adding mass to the solution.

Elimination of fans or operating them at lower RPMs can increase system reliability and lower maintenance costs. Passive solutions using heat pipes may increase performance at lower airflow than with conventional thermal solutions.

亞泰公司是專業研發、設計、生產、銷售大功率電子器件散熱器的制造企業。產品齊全，旗下包括水冷散熱器、熱管散熱器、風冷散熱器系列。主營鋁型材散熱器、板材散熱器、插片散熱器、IGBT散熱器、組合散熱器、高密齒散熱器及CNC加工等。公司廠區占地面積30000多平方米，員工300余人，年加工能力3000多噸，各種生產加工設備和檢驗設備齊全、工藝先進，可以進行各種表面處理，生產品種達600多種、上萬種規格，能夠滿足廣大客戶的各種需求。公司通過了高新技術企業的認定，ISO9001:2008質量體系認證、ISO14001：2004環境體系認證和ROHS認證，擁有幾十項專利證書。
